Starting and operating/Remote engine start system
you to start the engine (hybrid system)
from outside the vehicle. In addition, the
remote engine start system can activate
the heater or air conditioner, providing you
with a comfortable cabin upon entry.
& System operations
NOTE
For more details, refer to the Owner’s
Manual supplement for the remote
engine start system.
Access key
1) Lock button
An access key can be used as the remote
engine start transmitter. Operate the lock
button to start or stop the hybrid system as
follows.
! Before starting the hybrid system
Before using the remote engine start
system to start the hybrid system, confirm
the following conditions.
. The select lever is in the “P” position.
. All doors including the rear gate are
closed.
. The engine hood is closed.
. The push-button ignition switch is in the
“OFF” position.
! Starting the hybrid system
To start the hybrid system with remote
engine start system, briefly press the lock
button twice within 2 seconds, then press
and hold the lock button for 3 seconds.
1. Press the lock button briefly. The
hazard warning flashers then flash once.
2. Within 2 seconds, press the lock
button briefly again. The hazard warning
flashers then flash once again.
3. After step 2, immediately press and
hold the lock button. The hazard warning
flashers then flash once.
4. Approximately 3 seconds after step 3,
release the lock button. The hybrid system
will then start successfully.
7-13
system.
! Automatic engine shutdown
The remote engine start system will
automatically shut down or will not start
the hybrid system under the following
conditions.
. The total run-time has exceeded 20
minutes.
. Any door or the rear gate is opened.
. The select lever is moved to any
position other than “P”.
. The engine hood is opened.
. The push-button ignition switch is
pressed.
. The brake pedal is depressed.
. The engine speed is 3,000 rpm or
more.
The time setting until the hybrid system
automatically stops can be changed. To
change it, please contact your SUBARU
dealer. Note that some settings may
violate state, provincial, or local laws and
regulations. Check the laws in your area to
determine which setting is permitted.
! Stopping the hybrid system
Press and hold the lock button to stop the
hybrid system with remote engine start
– CONTINUED –
