Climate control/Manual climate control operation
both side windows to prevent fogging.)
and both side outlets of the instrument
panel (Refer to “Defrosting” F4-9.)
NOTE
You cannot drive using only the electric
motor power while selecting the “ ”
or “ ” mode. Even while selecting the
other mode, you may not drive using
only the electric motor power depending on the vehicle condition. For details, refer to “General information for
stopping/restarting of the engine and
electric motor” F9.
(Heat-def): Windshield defroster outlets,
foot outlets and both side outlets of the
instrument panel (Refer to “Defrosting”
F4-9.)
& Temperature control
Turn the temperature control dial to set the
preferred interior temperature. With the
dial set to your preferred temperature, the
system automatically adjusts the temperature of air supplied from the outlets so that
the preferred temperature is achieved and
maintained.
If the dial is turned fully counterclockwise,
the system provides maximum cooling
performance. If the dial is turned fully
clockwise, the system provides maximum
heating performance.
4-7
NOTE
The controllable temperature range
may vary depending on the regional
specifications of the vehicle.
! “DUAL” mode (type B)
You can change the setting of the driver’s
side and front passenger’s side temperature independently by selecting the
“DUAL” mode.
You can select the “DUAL” mode by
performing either of the following procedures.
. Press the “DUAL” button
. Turn the passenger’s side temperature
control dial
The “DUAL” mode can be canceled by
pressing the “DUAL” button.
When the “DUAL” mode is selected:
Turn the driver’s side dial to set the
driver’s side temperature. Turn the front
passenger’s side dial to set the front
passenger’s side temperature.
When the “DUAL” mode is canceled:
Set the desired temperature by turning the
driver’s side dial.
(Defrost): Windshield defroster outlets
– CONTINUED –
