3-22
Instruments and controls/Warning and indicator lights
NOTE
The brake vacuum pump system assists the boost pressure under the
following conditions.
. when driving only using the electric
motor power
. when driving at high altitudes while
the engine is cold
& Low fuel warning light
The low fuel warning light illuminates
when the tank is nearly empty, at approximately 1.8 US gal (7.0 liters, 1.5 Imp gal).
It only operates when the ignition switch is
in the “ON” position.
CAUTION
Promptly put fuel in the tank whenever the low fuel warning light
illuminates. Engine misfires as a
result of an empty tank could cause
damage to the engine.
NOTE
This light does not turn off unless the
tank is replenished up to an internal
fuel quantity of approximately 4.5 US
gal (17 liters, 3.7 Imp gal).
& Hill start assist warning
light/Hill start assist
OFF indicator light
! Hill start assist warning light
While the hybrid system is running, if there
are any malfunctions in the Hill start assist
system, the warning light will illuminate.
WARNING
When the Hill start assist warning
light illuminates, have the vehicle
inspected at an authorized SUBARU
dealer.
! Hill start assist OFF indicator light
While the Hill start assist system is
deactivated, the Hill start assist OFF
indicator light illuminates continuously to
inform the driver that the Hill start assist
system is not operational.
& Door open warning
light
The warning light illuminates if any door,
the rear gate is not fully closed. This
function is effective even if the ignition
switch is in the “LOCK” (off) or “ACC”
position, or the key is removed from the
ignition switch.
Always make sure this light is not illuminated before you start to drive.
& All-Wheel Drive v&
