Instruments and controls/Ignition switch
Ignition switch
& Models with push-button
start system
Your vehicle is equipped with the pushbutton ignition switch. For details, refer to
“Push-button ignition switch (models with
push-button start system)” F3-5.
& Safety precautions
. Before leaving the vehicle, always remove the key from the
ignition switch for safety and
never allow an unattended child
to remain in the vehicle. Failure
to follow this procedure could
result in injury to a child or
others. Children could operate
the power windows, the moonroof or other controls or even
make the vehicle move.
3-3
& Ignition switch positions
WARNING
. Never turn the ignition switch to
“LOCK” (off) while the vehicle is
being driven or towed because
that will lock the steering wheel,
preventing steering control. And
when the hybrid system is turned
off, it takes a much greater effort
than usual to steer.
CAUTION
Do not attach a large key holder or
key case to either key. If it banged
against your knees or hands while
you are driving, it could turn the
ignition switch from the “ON” position to the “ACC” or “LOCK” (off)
position, thereby stopping the hybrid system. Also, if the key is
attached to a keyholder or to a large
bunch of other keys, centrifugal
force may act on it as the vehicle
moves, resulting in unwanted turning of the ignition switch.
The ignition switch has four positions:
LOCK (off), ACC, ON and START.
NOTE
. Keep the ignition switch in the
“LOCK” (off) position when the hybrid
system is not running.
. Using electrical accessories for a
long time with the ignition switch in the
“ON” or “ACC” position can cause the
battery to go dead.
. If the ignition switch will not move
from the “LOCK” (off) position to the
“ACC” position, turn the steering wheel
slightly to the left and right as you turn
the ignition switch.
– CONTINUED –
