J
XV CROSSTREK
Continuously variable transmission (if equipped)
With the brake pedal
depressed, shift while
pressing the button in
Shift while pressing
the button in
Shift without pressing
the button
Models with
“L” position
Models with
manual mode
P = Park
To move the select lever
from Park: Firmly depress
brake pedal.
R = Reverse
N = Neutral
No gear engaged.
D = Drive
For normal driving.
M = Manual mode
L = L position
L position:
L is for using engine braking when going down a hill, etc. To select this mode, move the selector lever
from the D position to the L position.
Manual mode:
With the vehicle either moving or stationary, move the select lever from the D position to the M position to
select the manual mode.
Gearshifts can be performed using the shift paddle behind the
steering wheel.
To upshift to the next higher gear position, pull the shift paddle that
has + indicated on it. To downshift to the next lower gear position,
pull the shift paddle that has – indicated on it.
Rear view camera (if equipped)
When the ignition switch is ON and the select lever is set to R, the rear view camera automatically
displays the rear view image from the vehicle.
K
Vehicle Dynamics Control OFF switch
To deactivate Vehicle Dynamics Control, push switch.
light on the combination meter illuminates.
Deactivation should not be used except when absolutely necessary.
Please refer to Owner’s Manual for details on when Vehicle Dynamics
Control should be deactivated.
5
