E
XV CROSSTREK
Rear centre seatbelt (5-door)
2
3
4
5
To fasten:
1 Raise the head restraint to the extended position.
2 Remove the tongue plate from the belt holder on
the right side of the cargo area and pull out the
seatbelt slowly.
3 Pass seatbelt through the belt guide.
4 Insert webbing end to connector.
5 Fasten seatbelt in the usual way.
F
To unfasten:
Insert a tongue plate or other hard, pointed
object into the slot in the buckle.
See the Owner’s Manual Chapter 1 for details.
Folding down rear seatback
To fold rear seatback down,
pull knob and fold the seatback down.
G
Lower anchorages
Lower anchorages (bars) are provided for installing child
restraint system.
They are located where seat cushion meets seatback.
See the Owner’s Manual Chapter 1 for details.
H
Top tether anchorages
Top tether anchorages are provided for installing child restraint
system with top tether.
They are located on the back side of the rear seatback (5-door)
or on the rear shelf behind the rear seat (4-door).
See the Owner’s Manual Chapter 1 for details.
5-door
4-door
11
