Instruments and controls/Mirrors
6. When the indicator light flashes slowly
and then rapidly after several seconds,
release both buttons.
7. Plug the motor of the entrance gate/
garage door opener to the outlet.
8. Test your entrance gate/garage door
opener by pressing the programmed
HomeLink® button.
1)
2)
3)
HomeLink® button 1
HomeLink® button 2
HomeLink® button 3
2. Press and hold the two outer
HomeLink® buttons (button 1 and button
3) until the HomeLink® indicator light
begins to flash (after approximately 20
seconds). Then release both buttons.
3. Hold the end of the entrance gate’s/
garage door opener’s hand-held transmitter between 1 and 3 inches (25 and 76
mm) away from the HomeLink® button you
wish to program.
4. Press and hold the desired HomeLink®
button.
5. Press and release (“cycle”) the handheld transmitter button every 2 seconds
until step 6 is complete.
! Operating the HomeLink® Wireless Control System
Once programmed, the HomeLink® Wireless Control System can be used to
remote-control the devices to which its
buttons are programmed. To activate a
device, simply press the appropriate button. The indicator light illuminates, indicating that the signal is being transmitted.
! Programming other devices
To program other devices such as door
locks, home lighting and security systems,
contact HomeLink®
