Before Use

I Bluetooth signal quality icon

I Reception indicator

Displays the Bluetooth connection status of a cell phone.
• When a Bluetooth connection is established, “ ” and reception level
are displayed.

Displays the reception level.
• When "No Service" is displayed, the location is either outside the
service area or cannot be reached by the signal. In such situations,
the cell phone itself cannot be used. Move to a location where the
"No Service" display is no longer shown.
• Observe the following point when using handsfree operation with a
cell phone.

NOTE
• A Bluetooth communication antenna is embedded in the car display.
If a Bluetooth-enabled cell phone is used in the following locations or
conditions, the Bluetooth connection status display may turn gray or
Bluetooth connection may not be possible.
- When the cell phone is hidden from the display (when the cell phone is
behind or under a seat or in the glove box or console box).
- When the cell phone is touching or covered by a metal object.
To use a Bluetooth-enabled cell phone, move the phone to a location where
the blue display appears.
• When setting the cell phone to power saving mode, the Bluetooth
connection may be automatically disconnected. If this happens, switch off the
power saving mode of the cell phone.

I Battery indicator

- The reception level may not match the display of the cell phone. Depending
on the model, it may not be possible to display the reception level.
