Emergency Response (Continued)
Extrication (Continued)
Stabilize Vehicle
Crib at (4) points directly under the front and side sills.
Do not place cribbing under the orange colored power cables, exhaust system, or fuel system.
Note:
The XV Crosstrek Hybrid is equipped with a tire pressure monitoring system that by design
prevents pulling the valve stem with integral transmitter from the wheel. Snapping the valve stem
with pliers or removing the valve cap and Schrader valve will release the air in the tire.
Cribbing Points
LH
Fr
Rr
RH
① Cribbing Points
Valve Stem with Integral Transmitter Installed
on Wheel
Valve Stem with Integral Transmitter
① Metal
-36-
② Rubber
