Emergency Response (Continued)
Extrication (Continued)
Disable Vehicle
Performing any one of the following three procedures will shut the vehicle off and disable the
high voltage battery, SRS, and gasoline fuel pump.
Procedure #1
Mechanical Ignition Key System (Standard Equipment):
Note:
Before shutting off the vehicle and disconnecting the 12 Volt auxiliary battery, if necessary, lower
the windows, unlock the doors and open the rear gate as required. Once the 12 Volt auxiliary
battery is disconnected, power controls will not operate.
1. Confirm the status of the hybrid READY indicator light in the combination meter.
2. If the hybrid READY indicator light is illuminated, the vehicle is on and operational. Shut off the
vehicle by turning the ignition key off, removing the ignition key and placing it on the dash.
Note:
If the ignition switch will not move from the “LOCK” (off) position to the “ACC” position, turn
the steering wheel slightly to the left and right as you turn the ignition switch.
Hybrid READY Indicator Light
Turn Ignition Key Off
miles
The illustration above is a typical example. For
some models, the combination meter may be
slightly different than that shown in the
illustration.
-28-
