SRS Airbag( Supplemental Restraint System Airbag) ▽ Examples of the types of accidents in which the driver’ s / driver’ s and front passenger’ s SRS frontal airbag( s) are not designed to deploy in most cases
The driver’ s and front passenger’ s SRS frontal airbags are not designed to deploy in most of the following cases.
� If the vehicle is struck from the side or from behind
� If the vehicle rolls onto its side or roof
� If the vehicle is involved in a low-speed frontal collision p a b ■ 2
1
101315
1) |
First impact |
2) |
Second impact |
101395
In an accident where the vehicle is impacted more than once, the driver’ s and / or front passenger’ s SRS frontal airbag( s) will deploy only once on the first impact.
Example: In the case of a double collision, first with another vehicle, then against a concrete wall in immediate succession, once either or both of the driver’ s and front
▼
