SRS Airbag( S impact when any of the following conditions are met regarding the front passenger’ s seat.
� When the seat is occupied by an adult.
� When certain items( e. g. jug of water) are placed on the seat.
▽ If the passenger’ s frontal airbag OFF indicator light illuminates and the ON indicator light turns off even when the front passenger’ s seat is occupied by an adult CAUTION When the front passenger ' s seat is occupied by an adult, observe the following precautions. Failure to do so may lessen the load on the front passenger ' s seat, deactivating the front passenger ' s SRS frontal airbag despite the fact that the seat is occupied by an adult.
This may result in personal injury.
� Do not allow the rear seat occupant to lift the front passenger ' s seat cushion using his / her feet.
� Do not place any article under the front passenger ' s seat, or squeeze any article from behind and under the seat.
� Do not squeeze any article between the front passenger ' s seat and side trim / pillar, door or center console box. This may lift the seat cushion.
306789
: Front passenger’ s frontal airbag ON indicator light
: Front passenger’ s frontal airbag OFF indicator light
This can be caused by the adult incorrectly sitting in the front passenger’ s seat.
1. Turn the ignition switch to the“ OFF” position.
2. Ask the front passenger to set the seatback to the upright position, sit up straight in the center of the seat cushion, correctly fasten the seatbelt, position his /
