Other Bulbs
It may be difficult to replace the bulbs. We recommend that you have the bulbs replaced by your SUBARU dealer if necessary. ■ Adjusting Headlight Aim
3. Turn the bulb socket counterclockwise and remove it.
4. Pull the bulb out of the bulb socket and replace it with a new one.
5. Install the bulb socket by turning it clockwise.
6. Reconnect the electrical connector. 7. Reinstall the rear bumper cover.
■ Trunk Light CAUTION
B02122
Replacing the bulb could cause burns since the bulb may be very hot. Have the bulb replaced by your SUBARU dealer.
2
1) |
Adjustment bolt A |
2) |
Adjustment bolt B |
▼ Before checking the headlight aiming
1. Make sure the vehicle has a full tank of gasoline and the area around the headlight is not deformed.
2. Park the vehicle on level ground. 3. Sit in the driver’ s seat. 4. Bounce the vehicle several times.
1
B02156
