CAUTION
The sealant bottle and speed limit label need to be replaced after using the flat tire repair kit.
■ Tire Pressure Monitoring System( TPMS)( If Equipped) NOTE
New sealant and replacement parts can be purchased from your authorized repair shop or SUBARU dealer, and they should also be installed into the kit by a specialist. Empty sealant bottles and replacement parts must be returned to your SUBARU dealer or disposed of in compliance with local waste disposal regulations.
▼ Technical data of air compressor
Line voltage Operating voltage Amperage
DC 12 V DC 10 – 15 V Max. 10 A
702780
Low tire pressure warning light
The tire pressure monitoring system provides the driver with the warning message indicated by sending a signal from a sensor that is installed in each wheel when tire pressure is severely low.
The tire pressure monitoring system will activate only when the vehicle is driven. Also, this system may not react immediately to a sudden drop in tire pressure( for example, a blow-out caused by running over a sharp object).
