The indicator light will illuminate when a vehicle approaching from behind is detected.
The indicator light will flash to warn the driver of dangers under the following conditions.
� While the indicator light is illuminating, if the turn signal lever is operated toward the side in which this light turned on
� When reversing the vehicle while the system detects a vehicle approaching from either side
▽ BSD / RCTA approach indicator light dimming function
When the headlights are turned on, the brightness of the BSD / RCTA approach indicator light will be reduced.
NOTE
� You may have difficulty seeing the BSD / RCTA approach indicator light under the following conditions.- When sunlight shines directly on it- When the headlight beams from a vehicle traveling behind shines directly on it � While the illumination brightness control dial is in the fully upward position, even if the headlights are turned on, the brightness of the BSD / RCTA
approach indicator light will not be |
reduced. For details about the illumination |
brightness control dial, refer to |
" Illumination |
Brightness |
Control " |
�P134. |
|
|
▼ BSD / RCTA approach warning buzzer( only when reversing)
A warning buzzer sounds along with flashing of the BSD / RCTA approach indicator light to warn the driver of dangers.
The setting of the warning buzzer volume can be changed by operating the center information display. For details, refer to " Car settings " �P168. ▼ Safety tips regarding the BSD / RCTA approach indicator light / warning buzzer
� In the following cases, operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings.
- When a vehicle moves to the neighboring lane from a lane next to the neighboring lane- When driving on a steep incline or on repeated sharp uphill and downhill grades- When going beyond a pass
