� When waxing the vehicle, be careful not to apply the wax to the camera. If it comes in contact with the camera, moisten a clean cloth with a diluted neutral detergent to remove the wax. � The camera lens has a hard coating to help prevent scratches. However, when washing the vehicle or cleaning the camera lens, be careful not to scratch the camera lens. Do not use a washing brush directly on the camera lens. The image quality of the rear view camera may deteriorate. � Strong light shined on the camera lens may develop vertical lines around the light source. This is not a malfunction. � Under the fluorescent light, the display may flicker. However, this is not a malfunction. � The image of the rear view camera may be slightly different from the actual color of the objects. � If there is a malfunction on the center information display, refer to " Malfunctions of the Center Information Display " �P323.
■ How to Use the Rear View Camera
When the shift lever / select lever is set to“ R”, the rear view camera automatically displays the rear view image from the vehicle. When the lever is set to other positions, the image before setting to“ R” is displayed.
1. Set the ignition switch to“ ON”. 2. Set the shift lever / select lever to“ R”. NOTE
� The image of the rear view camera is horizontally reversed as is the case with the vehicle inside mirror or the outside mirror. � When“ Rear Camera Delay Control” is on, the rear view image from the rear view camera will be displayed on the center information display for a certain amount of time after the shift lever( MT models) or select lever( AT models) is shifted from“ R” to another position. When any of the following conditions are met, the rear view image will be canceled:- The select lever is shifted to“ P”( AT models)- The vehicle speed becomes approximately 5 mph( 8 km / h) or more- The parking brake is engaged- 9 seconds have elapsed since the shift lever( MT models) or select lever( AT models) was shifted from“ R” to another position
