C 3 ) Current engine speed The vertical bar will slide laterally according to the current engine speed .
This chart is intended for reference only and does not show the actual engine torque or output .
▼ Stopwatch 6
2 3 4
5
306803
1
Top screen
306802
Measurement screen |
1 ) |
Fastest lap time ( top screen ) |
2 ) |
Fastest lap time ( measurement screen ) |
3 ) |
Current lap time |
4 ) |
Total lap time |
5 ) |
Past lap times |
6 ) |
Meter control switch operation guide |
When the timer is reset , “ − − ’ − − ” − − ” will be displayed .
A maximum of 50 lap times can be recorded .
� Changing between the stopwatch screens� To change to the measurement screen : Press . � To change to the top screen : Press .
� Operating the measurement screen� : Start / stop measurement� : Mark off one lap�
