C ■ RAB Warning Indicator( If Equipped)
This indicator illuminates if the Reverse Automatic Braking( RAB) System malfunctions. Refer to " Reverse Automatic Braking( RAB) System( If Equipped)" �P278.
■ RAB OFF Indicator( If Equipped)
This indicator illuminates when the Reverse Automatic Braking( RAB) System is turned OFF, or when the Reverse Automatic Braking( RAB) System is suspended temporarily. Refer to " Reverse Automatic Braking( RAB) System( If Equipped)" �P278.
■ Sonar Audible Alarm OFF Indicator( If Equipped)
This indicator illuminates when the Sonar Audible Alarm function is turned OFF, or when the Sonar Audible Alarm function is suspended temporarily. Refer to " Reverse Automatic Braking( RAB) System( If Equipped)" �P278.
■ Master Warning Light
A buzzer sounds and the warning light comes on and flashes to indicate that the master warning system has detected a malfunction.
3-7. Combination Meter Display( Color TFT) WARNING Always pay adequate attention to safe driving when operating the combination meter display( color TFT) while the vehicle is in motion. When operation of the combination meter display( color TFT) interferes with your ability to concentrate on driving, stop the vehicle before performing operations on the screen. Also, do not concentrate on the display while driving. Doing so may cause you to look away from the road and could result in an accident.
Various information will be shown on the combination meter display( color TFT). Also, a warning message will appear on the display if a malfunction is detected. In addition, several settings for the displayed content can be performed.
