300 |
||||
|
� �
�
�
|
Do not jack up the vehicle with an object on or underneath the jack . The jack can be unstable and this can result in a severe accident .
Always turn off the engine before raising the flat tire off the ground using the jack . Never swing or push the vehicle supported with the jack . The jack can come out of the jacking point due to a jolt and this can result in serious injury or death .
All passengers must exit the vehicle before you raise it with the jack . Raising the vehicle with someone inside of it could result in serious injury or death .
Do not start the vehicle while it is supported by the jack . Doing so could result in serious injury or death .
|
NOTE
Contact a SUBARU dealer when jacking up the vehicle using a garage jack .
1 . Park on a hard , level surface , whenever possible , then stop the engine .
2 . Set the parking brake securely and shift the shift lever in reverse ( MT models ) or the select lever to the “ P ” ( Park ) position ( AT models ).
3 . Turn on the hazard warning flasher and unload all occupants and luggage from the vehicle .
|
5 w
T u " M
|
|
|
CAUTION
Do not hit and bend the disc rotor backing plate when removing and installing the tire . A bent backing plate may scrape against the disc rotor and cause noise while the vehicle is in motion .
|
901050
4 . Put wheel blocks at the front and rear of the tire diagonally opposite the flat tire .
|
6 u th ta |
||
