Reverse Automatic Braking ( RAB ) System ( If Equipped )
by SUBARU will not disclose or provide the acquired data to any other third party except under the following conditions .
� The vehicle owner has given his / her consent . � The disclosure / provision is based on a court order or other legally enforceable request . � Data that has been modified so that the user and vehicle cannot be identified is provided to a research institution for statistical processing or similar purposes .
■ Reverse Automatic Braking ( RAB ) System Overview
The Reverse Automatic Braking ( RAB ) system will operate the following 2 functions using 4 sonar sensors .
� Sonar Audible Alarm function
The Reverse Automatic Braking ( RAB ) system detects objects rearward and warns the driver by warning message on the center information display and warning beeps .
� Automatic Braking function
The Automatic Braking function detects objects rearward and if there is a high risk of a collision , the system decelerates the vehicle and controls the braking to reduce damage .
1
2 Object Close Behind
3 Apply Brake To Hold Posi
1 ) |
When reversing |
2 ) |
When either strong automatic braking or torque |
case , short warning beeps or continuous warn |
3 ) |
When the vehicle is stopped by the system ( in |
sounding ) |
4 ) |
Object ( e . g ., a wall ) |
