260
Rear View Camera � When waxing the vehicle , be careful not to apply the wax to the camera . If it comes in contact with the camera , moisten a clean cloth with a diluted neutral detergent to remove the wax . � The camera lens has a hard coating to help prevent scratches . However , when washing the vehicle or cleaning the camera lens , be careful not to scratch the camera lens . Do not use a washing brush directly on the camera lens . The image quality of the rear view camera may deteriorate . � Strong light shined on the camera lens may develop vertical lines around the light source . This is not a malfunction . � Under the fluorescent light , the display may flicker . However , this is not a malfunction . � The image of the rear view camera may be slightly different from the actual color of the objects . � If there is a malfunction on the center information display , refer to " Malfunctions of the Center Information Display " �P323 .
■ How to Use the Rear View Camera
When the shift lever / select lever is set to “ R ”, the rear view camera automatically displays the rear view image from the vehicle . When the lever is set to other positions , the image before setting to “ R ” is displayed .
1 . Set the ignition switch to “ ON ”. 2 . Set the shift lever / select lever to “ R ”. NOTE
� The image of the rear view camera is horizontally reversed as is the case with the vehicle inside mirror or the outside mirror . � When “ Rear Camera Delay Control ” is on , the rear view image from the rear view camera will be displayed on the center information display for a certain amount of time after the shift lever ( MT models ) or select lever ( AT models ) is shifted from “ R ” to another position . When any of the following conditions are met , the rear view image will be canceled : - The select lever is shifted to “ P ” ( AT models ) - The vehicle speed becomes approximately 5 mph ( 8 km / h ) or more - The parking brake is engaged - 9 seconds have elapsed since the shift lever ( MT models ) or select lever ( AT models ) was shifted from “ R ” to another position
