- Blinking or illuminated in RED : � Safely stop the vehicle as soon as possible , and refer to the emergency steps for the engine overheating . After that , have the system checked by your nearest SUBARU dealer . Refer to " Engine Overheating " �P315
- Blinking in RED and BLUE alternately : � The electrical system may be malfunctioning . Contact your SUBARU dealer for an inspection .
This coolant temperature low indicator light / coolant temperature high warning light has the following three functions .
� Illumination in BLUE indicates insufficient warming up of the engine
� Blinking in RED indicates that the engine is close to overheating
� Illumination in RED indicates overheating condition of the engine
For the system check , this indicator light / warning light illuminates in RED for approximately 2 seconds when the ignition switch is turned to the “ ON ” position . After that , this indicator light / warning light changes to BLUE and maintains illumination in BLUE . This BLUE illuminated light turns off when the engine is warmed up sufficiently .
If the engine coolant temperature increases over the specified range , the indicator light / warning light blinks in RED . At this time , the engine is close to overheating .
If the engine coolant temperature increases further , the indicator light / warning light illuminates in RED continuously . At this time , the engine may be overheating .
When the indicator light / warning light blinks in RED or illuminates in RED , safely stop the vehicle as soon as possible , and refer to the emergency steps for the engine overheating . Refer to " Engine Overheating " �P315 . After that , have the system checked by your nearest SUBARU dealer .
Also , if the indicator light / warning light often blinks in RED , the electrical system may be malfunctioning . Contact your SUBARU dealer for an inspection . NOTE
If the engine is restarted after a certain driving condition , this indicator light / warning light may illuminate in RED . However , this is not a malfunction if
