■ SRS Airbag System Warning Light WARNING
If the warning light exhibits any of the following conditions , immediately stop the vehicle in a safe place , and consult a SUBARU dealer . Unless a technician checks and repairs the system as needed , the seatbelt pretensioners and / or the SRS airbag will not operate properly in the event of a collision , which may result in injury .
� Flashing or flickering of the warning light
� No illumination of the warning light when the ignition switch is first turned to the “ ON ” position
� Continuous illumination of the warning light
� Illumination of the warning light while driving
For details about the components monitored by the warning light , refer to " SRS Airbag System Monitors " �P87 .
■ Front Passenger ’ s Frontal Airbag ON and OFF Indicators
306789
: Front passenger ’ s frontal airbag ON indicator
: Front passenger ’ s frontal airbag OFF indicator
The front passenger ’ s frontal airbag ON and OFF indicators show you the status of the front passenger ’ s SRS frontal airbag .
The indicators are located as shown in the illustration .
When the ignition switch is turned to the “ ON ” position , both the ON and OFF indicators illuminate for 6 seconds during which time the system is checked . Following the system check , both indicators turn off for 2 seconds . After that , one of the indicators illuminates depending on
