Windows blow and the windows will not be able to be opened or closed . If the windows cannot be opened or closed , check the fuses and replace them as necessary . Refer to " Fuses " �P367 . Also , after replacing a fuse , make sure to initialize the power windows . Refer to " Initialization of Power Window " �P118 .
▼ Anti-entrapment function
While closing the window automatically , if the window senses a substantial enough object trapped between the window and the roof side ( between the front pillar and a point over the rear seat ), it automatically moves down slightly and stops .
If a foreign object is caught while window is opening automatically , the window will stop .
�
�
CAUTION
Never attempt to test the power window operation using body parts fingers , hands or other parts of your body .
If an object is caught just before the window fully closes , the system may not operate properly .
NOTE
� If a window detects an impact similar to that caused by trapping an object ( for example , when the vehicle encounters a deep pothole ), the antientrapment function may operate . � You cannot close the window for a few seconds after the anti-entrapment function operates .
▼ Off delay function
The windows can be operated for approximately |
40 seconds even after the ignition |
switch is turned to the “ ACC ” or “ OFF ” |
position . If a door is opened within 40 |
seconds , |
the |
off |
delay |
function |
is |
canceled . |
|
|
|
|
|
▼
