The disc brakes have audible wear indicators on the brake pads . If the brake pads wear close to their service limit , the wear indicator makes a very audible scraping noise when the brake pedal is applied . If you hear this scraping noise each time you apply the brake pedal , have the brake pads serviced by your SUBARU dealer as soon as possible .
■ Breaking-in of New Brake Pads and Linings
When replacing the brake pad or lining , use only genuine SUBARU parts . After replacement , the new parts must be broken in as follows .
▼ Brake pad and lining
While maintaining a speed of 30 to 40 mph ( 50 to 65 km / h ), step on the brake pedal lightly . Repeat this five or more times .
▼ Parking brake lining
1 . Drive the vehicle at a speed of approximately 22 mph ( 35 km / h ).
2 . With the parking brake release button pushed in , pull the parking brake lever SLOWLY and GENTLY ( pulling with a force of approximately 33.7 lbf [ 150 N , 15.3 kgf ]).
3 . Drive the vehicle for approximately 220 yards ( 200 meters ) in this condition .
4 . Wait 5 to 10 minutes for the parking brake to cool down . Repeat this procedure .
5 . Check the parking brake lever travel . If the parking brake lever travel is out of the specified range , adjust it by turning the adjusting nut located on the parking brake lever .
Parking brake stroke : 7 – 8 notches / 45 lbf ( 200 N , 20.4 kgf )
WARNING
A safe location and situation should be selected for break-in driving .
CAUTION
Pulling the parking brake lever too forcefully may cause the rear wheels to lock . To avoid this , be certain to pull the lever up slowly and gently .
