Reverse Automat WARNING If your vehicle is trapped on a railroad crossing and you are trying to escape by reversing through the crossing gate , the system may recognize the crossing gate as an obstacle and brake may activate . In this case , remain calm and either continue to depress the accelerator pedal or cancel the system . To cancel the system , refer to " Canceling the Reverse Automatic Braking ( RAB ) System Operation " �P285 . ■ Operating Conditions
The Reverse Automatic Braking ( RAB ) system will operate when all of the following conditions are met .
2 3
1 ) |
EyeSight warning indicator |
2 ) |
RAB warning indicator |
3 ) |
RAB OFF indicator |
� The ignition switch is in the “ ON ” position .
� The EyeSight warning indicator is off . � The RAB warning indicator is off . � The RAB OFF indicator is off . � The select lever is in the “ R ” position . Sonar Audible Alarm function � The Sonar Audible Alarm is set to “ ON ”.
� The vehicle speed is from 0 to 9 mph ( 0 to 15 km / h ).
Automatic Braking function � The Automatic Braking is set to “ ON ”.
� The vehicle speed is from 1 to 9 mph ( 1.5 to 15 km / h ).
