272
BSD / RCTA ( If Equipped ) It is mounted on each side of the outside mirrors .
The indicator light will illuminate when a vehicle approaching from behind is detected .
The indicator light will flash to warn the driver of dangers under the following conditions .
� While the indicator light is illuminating , if the turn signal lever is operated toward the side in which this light turned on
� When reversing the vehicle while the system detects a vehicle approaching from either side ▽ BSD / RCTA approach indicator light dimming function
When the headlights are turned on , the brightness of the BSD / RCTA approach indicator light will be reduced .
NOTE
� You may have difficulty seeing the BSD / RCTA approach indicator light under the following conditions . - When sunlight shines directly on it - When the headlight beams from a vehicle traveling behind shines directly on it � While the illumination brightness control dial is in the fully upward position , even if the headlights are turned on , the brightness of the BSD / RCTA approach indicator light will not be reduced . For details about the illumination brightness control dial , refer to " Illumination Brightness Control " �P130 . ▼ BSD / RCTA approach warning buzzer ( only when reversing )
A warning buzzer sounds along with flashing of the BSD / RCTA approach indicator light to warn the driver of dangers .
The setting of the warning buzzer volume can be changed by operating the center information display . For details , refer to " Car settings " �P165 . ▼ Safety tips regarding the BSD / RCTA approach indicator light / warning buzzer
� In the following cases , operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings .
- When a vehicle moves to the neighboring lane from a lane next to the neighboring lane - When driving on a steep incline or on repeated sharp uphill and downhill grades - When going beyond a pass
