270
BSD / RCTA ( If Equipped ) Example 1
1 ) The detection range of the radar sensors
2 ) Area out of detection range of the radar sensors
A ) |
Vehicle that may not be detected |
B ) |
Parked vehicle |
WARNING
An approaching vehicle ( A ) may not be detected because the detection range is limited by the parked vehicle ( B ). Always be sure to check the surroundings with your eyes when reversing the vehicle .
C
701819
Example 2
1 ) The detection range of the radar sensors
1
C ) Vehicle that may be detected NOTE The system may detect that a vehicle ( C ) is passing in front of your vehicle . Always be sure to check the surroundings with your eyes when reversing the vehicle . ■ System Operation
▼ Operating conditions
The BSD / RCTA will operate when all of the following conditions are met .
� The ignition switch is in the “ ON ” position .
� The BSD / RCTA warning indicator and BSD / RCTA OFF indicator are turned off .
� The vehicle is driven at speeds above 7 mph ( 12 km / h ) ( except when reversing ).
� The shift lever / select lever is in the “ R ” position ( RCTA only ).
The BSD / RCTA will not operate in the following situations .
� The BSD / RCTA OFF indicator appears .
� The vehicle speed is below 6 mph ( 10 km / h ) even when the BSD / RCTA OFF indicator does not appear ( except when reversing ).
