264
Rear View Camera � �
�
�
If mud or snow sticks to or is frozen on the camera , you must be very careful when removing it . Otherwise , damage to the camera may cause a fire or electric shock . Pour water or lukewarm water over the camera to remove mud and ice , and wipe it with a soft , dry cloth .
Do not put a flame close to the camera or wiring . Otherwise , damage or fire may occur .
When replacing the fuse , be sure to use a fuse with the specified rating . Use of a fuse with a different rating may result in a malfunction .
If you use the rear view camera for a long time while the engine is not operated , the battery may become completely discharged .
NOTE
� Do not wipe the camera with alcohol , benzine or paint thinner . Otherwise , discoloration may occur . To remove contamination , wipe the camera with a cloth moistened with a diluted neutral detergent . Then wipe it with a soft , dry cloth .
� When waxing the vehicle , be careful not to apply the wax to the camera . If it comes in contact with the camera , moisten a clean cloth with a diluted neutral detergent to remove the wax . � The camera lens has a hard coating to help prevent scratches . However , when washing the vehicle or cleaning the camera lens , be careful not to scratch the camera lens . Do not use a washing brush directly on the camera lens . The image quality of the rear view camera may deteriorate . � Strong light shined on the camera lens may develop vertical lines around the light source . This is not a malfunction . � Under the fluorescent light , the display may flicker . However , this is not a malfunction . � The image of the rear view camera may be slightly different from the actual color of the objects . � If there is a malfunction on the center information display , refer to " Malfunctions of the Center Information Display " �P327 . ■ How to Use the Rear View Camera
When the shift lever / select lever is set to “ R ”, the rear view camera automatically displays the rear view image from the v p is
1 2 N
� h w o � is v c a m s W a c
