240
Automatic Transmission the shift paddle twice in rapid succession . � If the temperature of the transmission fluid becomes too high , the “ AT OIL TEMP ” warning light will illuminate . Immediately stop the vehicle in a safe place and let the engine idle until the warning light turns off .
▼ Temporary manual mode driving
While driving with the select lever in “ D ”, if a shift paddle is operated , the gear can temporarily be selected . In this case , “ M ” and the selected gear number will be displayed on the combination meter . ( If the engine speed approaches close to the red zone , an upshift will automatically be performed .)
2 1
The selected gear , from “ M1 ” to “ M6 ”, will be displayed on the combination meter . NOTE
� In the following situations , temporary manual mode will be cancelled . - When the vehicle speed is low - When the accelerator pedal is depressed continuously for a certain amount of time or more - When the accelerator pedal is depressed heavily - When the select lever is shifted to a position other than “ D ” - When the “+” shift paddle switch is held down for a period of time
When a downshift is attempted at a vehicle speed where a downshift is not possible ( when the engine speed would enter the red zone if a downshift is performed ), the downshift warning buzzer will sound to inform the driver that a downshift cannot be performed .
■ Driving Tips g fr s
� w “ R
� w th
� p “ D
� k a T m
1 ) |
Upshift |
2 ) |
Downshift |
702766
NOTE
If the accelerator and brake pedals are depressed at the same time , driving torque may be restrained . This is not a malfunction .
� On a road surface where there is a risk of wheelspin ( for example , a snow- or
