202 Manual Climate Control 403489
Heat : Foot outlets , both side outlets of the instrument panel and some through windshield defroster outlets ( A small amount of air flows to the windshield and both side windows to prevent fogging .)
403490
Heat-def : Windshield defroster outlets , foot outlets and both side outlets of the instrument panel ■ Temperature Control
Turn the temperature control dial to set the preferred interior temperature .
NOTE
The controllable temperature range may vary depending on the regional specifications of the vehicle .
▼ MAX A / C mode
For quicker cooling , press the MAX A / C button .
When the MAX A / C mode is on , the following settings will be changed automatically .
� The air conditioner will turn on .
� The temperature will be set on the lowest .
� The fan speed will be set on the maximum speed .
� The air inlet will be set to the recirculation mode .
� The airflow mode setting will be set to the ventilation mode .
To turn off MAX A / C mode and return the previous setting , press the MAX A / C button again .
▼
