dimming feature will default to on with each ignition cycle . ▼ To Operate the Compass Feature 1 . To turn the compass feature on / off , press and hold the “ ” switch for more than 3 seconds or until the display turns on / off . The compass feature will default to on with each ignition cycle .
2 . If the display reads “ C ”, slowly drive the vehicle in circles until compass is calibrated .
3
4 5
15 14 13
12
11
9 10
6 7 8
304866
Compass calibration zones 3 . To adjust for compass zone variance :
� Find your current location and zone number on the map . � Press and hold the “ ” switch for more than 6 seconds or until a zone number appears in the display .
� Once the zone number appears in the display , toggle the “ ” switch again until your current location zone number appears . After you stop pressing the switch , your new zone number will be saved . Within a few seconds , the display will show a compass direction . 4 . If the vehicle ’ s magnetics have changed or if the compass appears inaccurate , recalibrate the compass . Press and hold the “ ” switch for more than 9 seconds or until a “ C ” appears in the display . Once a “ C ” appears in the display , slowly drive the vehicle in circles until compass is calibrated .
▼ HomeLink ® Wireless Control System
The HomeLink ® Wireless Control System provides a convenient way to replace up to three hand-held radio frequency remotes used to activate devices such as gate operators , garage door openers , entry door locks , security systems , even home lighting . The below steps are generic programming instructions ; for Genie and Sommer garage door openers
please go directly to the HomeLink ® website . Additional information and programming videos can be found at
