E
Headlights/turn signal
1
1 Headlights
To turn on, rotate knob to:
: The side marker, parking, tail, license plate,
daytime running lights and instrument panel lights.
: The headlights and all the lights listed above (except
daytime running lights).
AUTO: The headlights, parking, daytime running lights and
so on turn on and off automatically.
: Off (The daytime running lights turn on.)
3
2
3
2 High/low beam change
To change to high beam, push lever forward.
To return, pull back to detent.
To flash high beams, pull lever toward you and release.
F
3 Turn signal
Move lever up or down.
Fog lights (if equipped)
1
: ON
2
: OFF
1
2
G
Windshield wiper and washer
1
2
3
1 Wiper
To operate, push lever down or up to the following positions:
: Temporary
: Off
: Intermittent
: Low speed
: High speed
2 Intermittent interval
To change interval speed, turn dial.
3 Washer/wiper dual operation
Pull the wiper control lever toward you. The wipers will
automatically operate a couple of times after the washer squirts
H
Outside rear view mirror switches
1 Turn the control switch to the side that you want to
adjust. L is for the left mirror, R is for the right mirror.
2 Move the control switch in the direction you want to
move the mirror.
1
2
4
Some functions are available on certain models. For detailed operating and safety information, please consult your Owner’s Manual.
