C
BRZ
Front seatbelt guide
To enable the seatbelt to be easily extended, pass the seatbelt
through the guide.
When getting in or out of the rear seats, release the seatbelt
from the guide.
D
Seat heaters (if equipped)
Press the switch to warm the seats.
1
1 Rapid heating
2 Normal heating
2
E
Folding down rear seatback
Pull the seatback lock release straps in the trunk lid
to fold down the seatback.
F
Lower anchorages
LATCH anchors are provided for both rear seats. (Buttons
displaying the location of the anchors are attached to the seats.)
See the Owner’s Manual Chapter 1 for details.
G
Anchor bracket (for top tether strap)
Anchor brackets are provided for both rear seats.
See the Owner’s Manual Chapter 1 for details.
11
