Read First
On-screen Buttons and Other buttons
To use this software, you normally have to touch the buttons on the touch screen.
You only need to confirm selections and changes when the application needs to be restarted, when an important setting is
changed, or when a section of the user's data/settings may be lost. Other than that, when using the button selected content is
saved immediately without requiring confirmation, and the new setting is applied.
Explanation
Use
Button
Type
Touch to start a function, open a new screen, and
save settings.
Touch once.
Button with
numbers displayed
Current fields or settings are displayed on the
Touch once.
button. Touch this button to change the value. After
changing, the value you enter is displayed on the
button.
Icon
Displays status information.
Some icons can also be used as buttons. Touch
once.
List
If there are multiple options available, the selection
items are displayed as a list.
To view the list, touch and slide your finger up and
down. Because the scrolling speed changes
depending on the speed of the slide, you can reach
the end of the list, with just a small, quick flick of
/ buttons,
your finger. Also, when using the
touch the number you want to move through the
pages.
When there are only a few selection items, you can
use the radio buttons instead of a list. Where only
one value can be selected.
Touch this button to select the new value.
Radio button
82 Navigation
Example
/
