2-2. Instrument cluster
Tachometer indicator needle movement function when starting
the vehicle
When the engine switch is turned to “ON” position (vehicles without a
keyless access with push button start system), or the push-button
ignition switch is turned to “ON” mode (vehicles with a keyless access
with push button start system), the tachometer indicator needle points
to the highest value once and then quickly returns.
I Changing between activated/deactivated
STEP 1
Press the “ODO/TRIP” switch repeatedly until the setting
screen is displayed. ( P. 189)
STEP 2
Each time the switch is pressed and held, the function
changes between activated/deactivated.
“S-on”: Activated
“S-oFF”: Deactivated
Setting the shift position indicator and shift-up indicator
(vehicles with a manual transmission)
Displaying of the shift position indicator and shift-up indicator can be
turned on/off.
STEP 1
Press the “ODO/TRIP” switch repeatedly until the setting
screen is displayed. ( P. 189)
STEP 2
Each time the switch is pressed and held, the display changes
between on/off.
“G-on”: Display on
“G-oFF”: Display off
190
