Read First
Most of these icons can be understood intuitively. The following table
shows the most frequently displayed route events. The symbol design is
the same in each field.
Icon
Explanation
Icon
Explanation
Turn left
Turn right
U-turn
Turn right & sharp curve.
Stay in the left lane.
Stay in the right lane.
Go straight ahead at the
intersection.
Turn left at the T junction.
Go left at the
roundabout. Third exit
(next change in
direction).
Join the roundabout (the
route change after the
next change).
Join the expressway.
Leave the expressway.
Board the ferry.
Disembark from the ferry.
You are half way to your
destination.
You have arrived at your
destination.
When using route guidance on roads with two or more lanes, it is
important that you drive in the correct lane. When lane information is
available on the Map, the lane and direction are indicated below the
map with small arrows. The lane that you should drive in is highlighted.
Keep right at the fork in
the road.
Turn left & sharp curve.
I Lane information & signs
90 Navigation
When detailed information is available, the arrows are removed and
signs are displayed. Signs are displayed at the top of the map. The color
and design of the signs is the same as signs actually found at the side of
the road or overhead signs. These signs show the district and the route
number for the lane direction.
