Child restraint systems 79 |
|||||||||
For booster seat : |
Raise the head restraint to the extended position . If the booster seat still makes contact , remove the head restraint . For details , refer to “ Head restraints ” FP48 .
CAUTION
Store the head restraint that has been removed in the cargo area . Do not place the head restraint in the passenger compartment to prevent it from being thrown around in the passenger compartment in a sudden stop or a sharp turn .
|
For booster cushion :
Raise the head restraint to the extended position . Do not remove the head restraint .
|
3 . Place the booster seat / cushion and sit the child on it . The child should sit well back on the booster seat / cushion .
4 . If there is a gap between the booster seat / cushion and the seatback , adjust the seatback angle until good contact is achieved .
5 . Run the lap and shoulder belt following the instructions provided by its manufacturer . For booster seat / cushion with a belt guide , use the seatbelt through the belt guide .
6 . Insert the tongue plate into the buckle until you hear a click . Take care not to twist the seatbelt . Make sure the shoulder belt is positioned
|
across the center of child ’ s shoulder and that the lap belt is positioned as low as possible on the child ’ s hips . |
7 . To unfasten the seatbelt , press the release button on the seatbelt buckle and allow the belt to retract .
WARNING
. Never use a belt that is twisted or reversed . In an accident , this can increase the risk or severity of injury to the child .
. Never place the shoulder belt under the child ’ s arm or behind the child ’ s back . If an accident occurs , this can increase the risk or severity of injury to the child .
– CONTINUED –
|
Seat , seatbelt and SRS airbags |
