Child restraint systems 73 |
|||||||||
|
& When installing the forward facing child restraint system on the front passenger ’ s seat
S01AG15
|
install it on the front passenger ’ s seat .
Only forward facing child restraint systems ( including booster seats ) can be installed on this seat and should only be installed when it is unavoidable . When you install a forward facing child restraint system to the front passenger ’ s seat , perform the following procedure .
|
3 . Place and secure the child in the child restraint system .
4 . Check that the front passenger ’ s frontal airbag ON / OFF indicator light status meets the requirements of your child restraint system .
|
Seat , seatbelt and SRS airbags |
||||||
WARNING |
|||||||||
|
. NEVER INSTALL A REARWARD FACING CHILD RESTRAINT SYS- TEM ON THE FRONT PASSEN- GER ’ S SEAT . DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD ’ S HEAD TOO CLOSE TO THE SRS AIRBAG .
. The front passenger ’ s seat is not equipped with tether anchorages . Therefore , when installing a child restraint system that uses tether straps , do not
|
A B
Seat position : Rearmost as possible Seatback : Upright
1 . Adjust the front passenger ’ s seat as illustrated .
2 . Install the child restraint system to the front passenger ’ s seat . Refer to “ Installing a forward facing child restraint system ” FP76 .
|
: Front passenger ’ s frontal airbag ON indicator light
: Front passenger ’ s frontal airbag OFF indicator light
When front passenger ’ s frontal airbag OFF indicator light is illuminated : Only forward facing child restraint systems can be installed on the front passenger ’ s seat . When front passenger ’ s frontal airbag ON indicator light is illuminated : When the indicator is illuminated , child
|
|||||||
– CONTINUED – |
