530
Tire information
Type B
( 1) DOT symbol *( 2) Plant Code( 3) Manufacturer’ s Code( 4) Date of Manufacture
The first two figures identify the week, starting with“ 01” to represent the first full week of the calendar year; the second two figures represent the year. For example, 0101 means the 1st week of 2001.
*: The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
! Other markings
S13AB0103
The following makings are also placed on the sidewall.
! Maximum permissible inflation pressure
S13AB010301
The maximum cold inflation pressure to which this tire may be inflated. For example,“ 300 kPa
( 44 PSI) MAX. PRESS”
! Maximum load rating
S13AB010302
The load rating at the maximum permissible weight load for this tire. For example,“ MAX. LOAD 580 kg( 1,279 LBS) @ 300 kPa( 44 PSI) MAX. PRESS.”
WARNING
Maximum load rating applies only to the tire, not to the vehicle. Putting a load rated tire on any vehicle does not mean the vehicle can be loaded up to the tire’ s rated load.
! Construction type
S13AB010303
Applicable construction of this tire.
For example,“ TUBELESS STEEL BELTED RADIAL”
! Construction
S13AB010304
The generic name of each cord material used in the plies( both sidewall and tread area) of this tire.
For example,“ PLIES: TREAD 2 STEEL + 2 POLYESTER SIDE- WALL 2 POLYESTER”
! Uniform Tire Quality Grading( UTQG)
S13AB010305
For details, refer to“ Uniform tire quality grading standards” FP540.
& Recommended tire inflation pressure
S13AB02
! Recommended cold tire inflation pressure
S13AB0201
For recommended cold tire inflation pressure for your vehicle’ s tires, refer to“ Tires” FP520.
