44
Seats
|
the holder .
4 . Lower the headrest to the storage position . Refer to “ Head restraints ” FP48 .
|
|
|
|
6 . Pull the lever to unlock the seatback . The seatback will be folded down .
7 . Slide the folded second seats backward until they lock .
8 . To return the seatback to its original position , raise the seatback until it locks into place . Make sure it is securely locked .
|
! Captain seat |
S01AQ070401 |
5 . Pull the lever and tilt the seatback forward .
! Armrest WARNING
S01AQ0704
Do not hook the seatbelt onto the armrest when the seatbelt is fastened . The seatbelt may be unable to fulfill its intended function in the event of an accident , possibly resulting in serious injury .
Lower the armrest to use it . To lower the armrest position :
First lift it all the way to the top position , then lower it to the bottom position .
To raise the armrest position :
Lift the armrest from the bottom position to the desired height .
