490
Brake pedal
Alcohol contained in the brake fluid may damage them.
. Be careful not to spill brake fluid when adding it. If brake fluid touches the exhaust pipe, it may cause a bad smell, smoke, and / or a fire. If brake fluid gets on the exhaust pipe, be sure to wipe it off.
Visually check the brake fluid level of the reservoir monthly on the even surface.
& Recommended brake fluid
S11AO02
Refer to“ Fluids” FP519. CAUTION
Never use different brands of brake fluid together. Also, avoid mixing DOT 3 and DOT 4 brake fluids even if they are the same brand.
11-13. Brake pedal
S11AR
Check the brake pedal free play and reserve distance according to the maintenance schedule in the“ Warranty and Maintenance Booklet”.
1“ MAX” level line 2“ MIN” level line
Be sure to check the brake fluid level from the outside of the reservoir. If the fluid level is below“ MIN”, top up brake fluid to“ MAX”. Use only brake fluid from a sealed container.
