446
Spare tire
CAUTION
When using the spare tire hoist:
Do not use air tools or power tools to turn the spare tire hoist shaft end. If you do, it could result in severe mechanical damage to the spare tire hoist.
& Re-storage of spare tire
S09AK02
1. Turn the spare tire hoist shaft end counterclockwise with the wheel nut wrench to loosen the cable sufficiently enough to allow the cable end retainer go through center hole of the temporary spare tire.
2. Insert the retainer through the center hole of the temporary tire as showing in the figure.
3. Turn the hoist shaft end clockwise with the wheel nut wrench to wind the cable up completely until you hear a few clicking sounds. Confirm that the temporary spare tire holding cable has been wound up completely by shaking the temporary tire.
CAUTION
If the temporary spare tire is not stored securely, it could damage adjacent areas of the vehicle and make an abnormal noise.
4. Install the rubber cap. 5. Install the cover.
6. Store the wheel nut wrench, two extensions, jack and jack handle in
