cancel the system, refer to“ Canceling the Reverse Automatic Braking( RAB) system operation” FP396.
& Operating conditions
S07BN02
The Reverse Automatic Braking( RAB) system will operate when all of the following conditions are met.
1 EyeSight warning indicator 2 RAB warning indicator 3 RAB OFF indicator 4 Sonar Audible Alarm OFF indicator
. The ignition switch is in the“ ON” position.
. The EyeSight warning indicator is off.. The RAB warning indicator is off.. The RAB OFF indicator is off.
|
. The select lever is in the“ R” position.
. Sonar Audible Alarm OFF indicator is off.
|
Sonar Audible Alarm function. The Sonar Audible Alarm is set to“ ON”.
. The vehicle speed is from 0 to 9 mph( 0 to 15 km / h).
Automatic Braking function. The Automatic Braking is set to“ ON”.
. The vehicle speed is from 1 to 9 mph( 1.5 to 15 km / h).
NOTE
. In the following cases, the Reverse Automatic Braking( RAB) system will not operate. Promptly contact a SUBARU dealer to have the system inspected. – The EyeSight warning indicator is illuminated. – The RAB warning indicator is illuminated.
. In the following cases, the Reverse Automatic Braking( RAB) system cannot be operated. – The( EyeSight Temporary Stop indicator: White) is illuminated, and the messages corresponding to the EyeSight temporary stop are displayed on the combination
|
meter display( color LCD). For details, refer to the Owner’ s Manual supplement for the EyeSight system.
– The RAB OFF indicator is illuminated.
. In the following cases, the functions may not be able to properly work. Promptly contact a SUBARU dealer to have the system inspected. – A sticker, paint, or a chemical is applied to the sonar sensors or the rear bumper. – The rear bumper is modified. – The rear bumper has been removed and attached.
– The ground clearance is changed due to the vehicle’ s loading condition or modification.
– There is damage to the sonar sensors or the rear bumper.
– The rear bumper is exposed to strong impact, or the rear bumper is deformed.
. On a steep hill, the system’ s automatic braking ability will be reduced.
. The system is designed to avoid collisions by automatic hard braking when the vehicle’ s reversing speed is less than approximately 3 mph( 5 km / h). However, the system does not guarantee that the vehicle will be
|
Starting and operating |
|
– CONTINUED – |
