268
Mirrors
& Outside mirrors
S03AP03
! Convex mirror( passenger side)
S03AP0301
WARNING
Objects look smaller in a convex mirror and farther away than when viewed in a flat mirror. Do not use the convex mirror to judge the distance of vehicles behind you when changing lanes. Use the inside mirror( or glance backwards) to determine the actual size and distance of objects that you view in convex mirror.
CAUTION
Make sure to adjust the mirrors before driving.
! Remote control mirror switch
S03AP0302
: Select side to adjust: Direction control
The remote control mirrors operate only when the ignition switch is in the“ ON” or“ ACC” position.
1. Turn the control switch to the side that you want to adjust.“ L” is for the left mirror,“ R” is for the right mirror.
2. Move the control switch in the direction you want to move the mirror.
3. Return the control switch to the neutral position to prevent unintentional operation.
NOTE
. The mirrors can also be adjusted manually.
For models with memory function:
. The outside mirror can be adjusted for approximately 45 seconds after the following conditions are met. – The ignition switch is turned to the“ OFF” position. – The door is unlocked using the access key fob.
. The outside mirror angle can be registered with button“ 1”,“ 2” or each of the key fobs. For details, refer to“ Power driver’ s seat with synchronized outside mirrors memory function” FP37.
. The outside mirror angle can also be retrieved with the Driver Monitoring System user information. To do so, perform user registration in the Driver Monitoring System settings. Refer to“ Driver Monitoring System” FP220.
! Reverse tilt-down feature( if equipped)
S03AP030201
When backing the vehicle up, the right and / or left outside mirrors will turn downward automatically to provide better rear visibility.
1. Push the ignition switch to the ON position.
2. Move the select lever to the R( Reverse) position.
