Hazard warning flasher
|
3-2. Hazard warning flasher
S03AB
|
|
|
|
|
3-3. Meters and gauges
NOTE
Some of the meters and gauges on the combination meter use liquid-crystal displays. You will find their indications hard to see if you wear polarized glasses.
|
S03AD |
& Odometer |
S03AD04 |
|
& Speedometer
S03AD03
The speedometer shows the vehicle speed.
|
The hazard warning flasher is used to warn other drivers when you have to park your vehicle under emergency conditions. The hazard warning flasher works regardless of the position of the ignition switch.
To turn on the hazard warning flasher, push the hazard warning flasher switch on the instrument panel. All the turn signal lights and the turn signal indicator lights will flash. To turn off the flasher, push the switch again.
NOTE
When the hazard warning flasher is on, the turn signals do not work.
& Tachometer
S03AD06
The tachometer shows the engine speed in thousands of revolutions per minute.
CAUTION
Do not operate the engine with the pointer of the tachometer in the red zone. In this range, fuel injection will be cut by the engine control module to protect the engine from overrevving. The engine will resume running normally after the engine speed is reduced below the red zone.
1 TRIP RESET switch 2 Combination meter
This meter displays the odometer when the ignition switch is in the“ ON” position.
The odometer shows the total distance that the vehicle has been driven.
NOTE
If you press the TRIP RESET switch when the ignition switch is in the“ OFF” or“ ACC” position, the odometer / trip meter will light up.
The indicators will turn off when:
. The TRIP RESET switch is not operated for approximately 10 seconds.
. The driver’ s door is opened and then closed.
