monitors, refer to“ Components” FP94. Note that the diagnostic system does not monitor the SRS airbag system warning light itself.
WARNING
If the warning light exhibits any of the following conditions, immediately stop the vehicle in a safe place, and consult a SUBARU dealer. Unless a technician checks and repairs the system as needed, the seatbelt pretensioners and / or the SRS airbag will not operate properly in the event of a collision, which may result in injury.
. Flashing or flickering of the warning light
. No illumination of the warning light when the ignition switch is first turned to the“ ON” position
. Continuous illumination of the warning light
. Illumination of the warning light while driving
|
& SRS airbag system servicing
S01AH05
WARNING
. When discarding an airbag module or scrapping the entire vehicle damaged by a collision, consult your SUBARU dealer.
. The SRS airbag has no userserviceable parts. Do not use electrical test equipment on any circuit related to the SRS airbag system. For required servicing of the SRS airbag, consult your nearest SUBARU dealer. Tampering with or disconnecting the system’ s wiring could result in accidental inflation of the SRS airbag or could make the system inoperative, which may result in serious injury.
|
CAUTION
If you need service or repair in areas indicated in the following list, have the work performed by an authorized SUBARU dealer. The SRS airbag control module, impact sensors and airbag modules are stored in these areas.
|
. Under the center of the instrument panel
. On both the right and left sides at the front of the vehicle
. Steering wheel and column and nearby areas
. Bottom of the steering column and nearby areas
. Top of the dashboard on front passenger’ s side and nearby areas
. Each front seat and nearby area. Inside each center pillar. Inside each front door
. In each roof side( from the front pillar to a point over the rear seat)
. Between the rear seat cushion and rear wheel house on each side
. Under the second-row center seat
In the event that the SRS airbag is deployed, replacement of the system should be performed only by an authorized SUBARU dealer. When the components of the SRS airbag system are replaced, use only genuine SUBARU parts.
|
