Mirrors 259 |
||||||||||
|
! How to use the Smart Rearview Mirror
S03AP1103
CAUTION
Adjust the rearview mirror before driving .
1 ) Change the Smart Rearview Mirror to the mirror mode .
2 ) Sit with the correct posture in the driver ’ s seat and adjust the mirror position to see behind .
3 ) Change the Smart Rearview Mirror to the display mode .
If you start driving without adjusting the mirror , light may reflect on the mirror while selecting the display mode and it may make it hard to see the screen .
|
! To change the mode
S03AP110301
|
1 To select the display mode , first adjust the rearview mirror , then pull the mode lever towards you .
2 To select the mirror mode , push the mode lever away from you .
Select the display mode to show the image from the camera that is installed on the rear gate .
Select the mirror mode to use as a normal mirror . If the mirror mode is selected , the image from the camera is not shown on the mirror .
NOTE
. It is not possible to use the Smart Rearview Mirror in the display mode when the ignition switch is in the “ LOCK ”/“ OFF ” or “ ACC ” position .
|
. When using the display mode , parts of the vehicle interior may reflect light on the display . Adjust the angle of the Smart Rearview Mirror to avoid unwanted reflection .
! Display adjustment
1 Left button 2 Center button 3 Right button
S03AP110307
Press any of the left , center or right buttons to display the main menu .
NOTE
The main menu cannot be displayed on the display while the select lever is in a position other than the “ P ” position .
|
Instruments and controls |
||||||
– CONTINUED – |
