Center information display ( CID ) 213 |
|||||||||||
|
! Driver profiles icon
S03BS050105
Touch ( driver profiles icon ) to confirm the driver ’ s information . For details , refer to the separate navigation / audio Owner ’ s Manual .
! HOME icon
S03BS050106
Touch ( HOME ) to display the top menu .
! Climate control screen
S03BS050107
The climate control status is shown on the screen .
|
7 SYNC mode indicator
8 Set temperature indicator ( passenger ’ s side )
9 REAR SYNC mode indicator 10 REAR set temperature
11 Front passenger ’ s seat heater / ventilation icon ( if equipped )
12 Customizable icon 13 REAR Climate control ON / OFF icon 14 Fan speed control 15 Climate control ON / OFF icon
When operating the climate control system , the main screen switches to the climate control screen . For details , refer to “ Climate control panel ” FP283 .
! Main screen
|
S03BS0502 |
settings will be explained . For details about other items , refer to the separate navigation / audio Owner ’ s Manual .
– “ Settings ” ? “ General ” – “ Settings ” ? “ Car ” – “ Car Info ”
|
! General settings
S03BS050201
Set the time and display general items .
|
Instruments and controls |
||||||
|
1 Driver ’ s seat heater / ventilation icon ( if equipped )
2 Set temperature indicator ( driver ’ s side ) 3 Airflow mode 4 Climate control mode 5 Air inlet selection 6 Air conditioner ON indicator
|
To display the main screen , touch ( HOME ).
In this Owner ’ s Manual , the following
|
1 . Touch ( HOME ). 2 . ? ( Settings ) 3 . ? “ General ” 4 . Select the preferred menu . |
|||||||||
– CONTINUED – |
