204
Center information display ( CID )
underground parking area or when passing through a tunnel )
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Celsius ( 8C ) or Fahrenheit ( 8F ). For details , refer to “ General settings ” FP213 .
3-8 . Center information display ( CID )
WARNING
S03BS
Always pay attention to safe driving when operating the center information display while the vehicle is in motion . When operation of the center information display is disturbing your awareness and ability to concentrate on driving , stop the vehicle in a safe place before performing operations on the display . Also , do not concentrate on the display while driving . Doing so could result in an accident .
& Features
S03BS01
All information is displayed on the center information display , including vehicle settings , vehicle status , navigation system ( if equipped ) operation , audio operation , and climate control operation .
Interruption screen |
205 |
Vehicle status and |
maintenance information |
207 |
|
Vehicle settings |
213 |
Climate control operations |
213 |
Surround View Monitor ( if equipped )/ Rear view camera
Navigation system
Audio / telephone
EyeSight
324 / Refer to the navigation / audio Owner ’ s Manual .
Refer to the navigation / audio Owner ’ s Manual .
Refer to the navigation / audio Owner ’ s Manual .
Refer to the Owner ’ s Manual supplement for the EyeSight system .
The center information display can also be used to set and initialize the center information display itself .
NOTE
. When the vehicle is in motion , certain functions and selections may not be available .
. The language and units for both the center information display and the combination meter display ( color LCD ) can be changed . For details
